XB7NG21 XB7NG25 XB7NG33 XB7-EG21 1NO XB7NG25 1NO 1NC XB7-EG33 2NO 3 Position XB7 Key Selector Switch

XB2 Pushbutton XB2-BS542 XB2-BD21 XB2-BA31 XB2-BD53 XB2-BG73 XB2-EV164 22mm Waterproof IP65 IP67 LAY5 XB2 Push button Switch

Switch Combination:1NO1NC,1NO,2NO2NC,2NO
Whether the smart:NO
Brand Name:Newtrend or OEM brand
LED:NO
Place of Origin:China
Max. Current:10A
Model Number:XB2
Max. Voltage:380V
IP level:IP65,IP54,IP67
Protection Level:IP65/IP66/IP67
SKU: 60043115421 Category:
Description

XB2 Pushbutton XB2-BS542 XB2-BD21 XB2-BA31 XB2-BD53 XB2-BG73 XB2-EV164 22mm Waterproof IP65 IP67 LAY5 XB2 Push button Switch



Product Application

XB2 series push button are used in controlling circuit of AC voltage up to 660V/AC50Hz or 60Hz,and DC voltgae below 400V. It is used for controlling signal and interlocking purposes. The main body of the push buttons adopts zinc alloy and high-grade anti-flam plastic. The contact adopts special silver alloy in order to enjoy the benefit of high anti-electrical erosion. The signal lamp series are suitable for electrical appliances circuit of AC voltage up to 380V/50Hz,and DC voltage below 380V.It is ideal for using as indicating signals,warning signal,emergency signal,etc. Our products comply with GB/T14048.1 and IEC60947-5-1,all prouducts are CE,IOS9001,ROHS and UL certified.

Main technical parameter

Basic technical parameter of button
Basic technical parameter of signal lamp
Rated insulation
AC 600V(50Hz/60Hz)
Insulation resistance
≥50MΩ
Conventional heating current
10A
Contact resistance
≤25MinΩ
Insulation resistance
≥50MΩ
Pf withstand voltage
AC 2.5KV/min
Contact resistance
≤25MinΩ
Voltage wave
±20%
Mechanical life
100×10000

pushbutton
50×10000

selector switch
Brightness
60cd/m2
Electrical life
500×10000

pushbutton
25×10000

Selector switch
Continuous working life
10x10000h

Additional information
Weight 2 kg
Dimensions 25 × 25 × 25 cm
Color

Blue, Black, White, Red, Yellow, Green, Orange
