W50-T-P-DE (DC66P), W100-T-P-DE (DC88P) DC Contactors has been designed for direct current DC loads, particularly motors used on electric winches and electric vehicles.
– Motor Reversing DC Contactor
– Coil Voltage: 12Vdc or 24Vdc or 48Vdc
– Paired Single Pole Double Throw (Double Pole, Changeover Contacts)
– Ideal for Marine Applications, such as, Bow Thrusters, Windless and Winches.
| Model |
W50-T-P-DE (DC66P) |
W100-T-P-DE (DC88P) |
| Photo |  |
 |
| Coil Voltage | 12VDC, 24VDC, 48VDC, 72VDC etc | |
| Rated Voltage of Contact Circuit | ≤48VDC | |
| Rated Continous Current | 50A | 100A |
| Rated Intermittent Current | 250A | 500A |
| Dielectric Voltage Strength | 50Hz 1000V AC 1min | |
| Volt Drop of Main Contact | < 100mV | |
| Mechanical life | 100 thousand times | |
| Electric life | Continous 20 thousand times, Intermittent 2 thousand times | |
| Contact Form |
Double Pole, Changeover Contacts (Paired Single Pole Double Throw) |
|
| Coil Power | 25-27W | 29-31W |
| Typical Pull-In Time (N/O Contacts to Close) |
<30ms | |
| Typical Drop-Out Time (N/O Contacts to Open) |
<50ms | |
| Pull-In Voltage (Coil at 20℃) | <75%Us | |
| Drop-Out Voltage (Coil at 20℃) | 5% – 40% | |
| Main stud terminals | M8 | |
| Feature | Waterproof, Heavy load for various Winches, Windless, etc | |
| Wiring Diagram |  |
|
W50-T-P-DE (DC66P) Installation Diagram:
W100-T-P-DE (DC88P) Installation Diagram:
